ATLAS ELEKTRONIK UK (AEUK) have added an underwater surveillance system to their already established fleet of ARCIMS Uncrewed Surface Vessels (USVs). Integrated with a compact Variable Depth Sonar (VDS) ‘SeaSense’, this underwater threat detection capability has been designed to operate within confined and shallow waters, offering an alternative to the traditional ASW platform.
What we have here is a combination of two systems, both of which may be of interest, a lightweight sonar system and an optionally manned 11 meter boat that is essentially a maritime pickup truck that can handle alternative mission loads. Apparently, there is also a mine countermeasures system based on the same 11 meter uncrewed surface vessel.
That the ARCIMS platform is an 11meter boat immediately piqued my interest because it is the same size as the Long Range Interceptor carried by National Security Cutters (NSC), suggesting the craft might be operated from NSC with minimal changes.
A couple of NSCs with MH-60R ASW helicopters and four of these sonar equipped optionally manned boats might make a pretty robust deployable ASW screen for an Amphibious Objective Area or a port of debarkation without major changes to the NSCs.
191227-N-PY805-1005 SOUTH CHINA SEA (Dec. 27, 2019) The Independence-variant littoral combat ship USS Gabrielle Giffords (LCS 10) receives fuel from the Henry J. Kaiser-class fleet replenishment oiler USNS Pecos (T-AO 197) during a replenishment-at-sea. Gabrielle Giffords is on a rotational deployment to INDOPACOM, conducting operations, exercises and port visits throughout the region and working hull-to-hull with allied and partner navies to provide maritime security and stability, key pillars of a free and open Indo-Pacific. (U.S. Navy photo by Nicholas J. Beihl/Released)
Two reports, one from US Naval Institute and one from Defense News. They appear to disagree, but they both were based on the same presentation. Really it is good news that both 5th and 7th Fleet want Independence class LCS. Trouble is, they don’t think they have enough to go around, if they are all based in San Diego, as they currently are. So, the Navy is looking at alternatives including forward basing or using other assets to provide the required Mine Counter Measures capability to 5th Fleet.
Their decision has potential consequences for Coast Guard forces’ efforts in the Eastern Pacific drug transit zone, Western Pacific IUU fisheries enforcement, and Southwest Asia.
The US Naval Institute report basically says the current plan is to supply 5th Fleet’s MCM requirement by using Independence class LCS operating from their base in San Diego, but they are looking at alternatives including forward basing or perhaps letting Freedom class LCS fill in.
The Defense News report tells us why the Navy wants an alternative solution.
The U.S. Navy is considering alternatives to deploying littoral combat ships to the Middle East for a mandatory mine countermeasures mission, hoping to instead maintain LCS deployments to the Western Pacific. (2)
—
“We’re trying to leverage that as much as we can and see how that fits into the mix,” he said. “There’s several different things going on, but right now I think the plan of record as it stands would be an Independence-variant MCM capability out there — but … we are working on several other options to see how we can fill that, and I personally think the answer is going to be something that is forward-deployed to Bahrain.” (Emphasis applied–Chuck)(2)
The Independence class (trimaran) LCSs in the Western Pacific are, or at least could be, helping to counter Illegal, Unreported, and Unregulated (IUU) fishing.
Once expected to go to the 5th Fleet/CENTCOM, the remaining Freedom class (mono-hull) LCSs are now expected to support 4th Fleet/SOUTHCOM including drug interdiction with embarked Coast Guard Law Enforcement Teams. If they are diverted to 5th Fleet to fill in, it could potentially hurt the drug interdiction effort.
An Alternative: As MCM can now be modularized, there appears to be less reason to have dedicated MCM ships or that all the elements have to be collocated on a single ship.
The service plans to buy 24 packages to equip 15 of the Independence-class LCS. That leaves nine mine countermeasure packages for potential use on “vessels of opportunity,” as Capt. Mike Egan, branch head for mine warfare in the Office of the Chief of Naval Operations, said last May at the 2022 International Mine Warfare Technology Symposium of the Mine Warfare Association. (3)
The aviation components and the Uncrewed Surface Vessel and its mine hunting sonar could be operated from shore or from an Expedition Base Ship. The Lionfish Unmanned Underwater Vehicle is the Remos 300. It is relatively small.
Part of the Navy’s planned family of systems, Lionfish’s main role will be intelligence gathering with the Navy’s expeditionary mine countermeasures company. As its name suggests, the SUUV is only 150 pounds and requires just a few sailors to deploy it. It will be based on HII’s Remus 300, a “man-portable UUV” that is “designed for modularity… [and] can be reconfigured with a range of sensors and payloads to meet mission requirements,” according to a statement the company published last year when announcing the government of New Zealand had ordered four UUVs. (4)
It could be operated from shore, from Expeditionary MCM Company RHIBs, or from Webber class WPBs.
Naval Strike Missile: Incidentally, there is affirmation that the Freedom class LCS, in addition to the Independence class LCS, will be equipped with Naval Strike Missile. From the USNI post,
“As of right now, the Navy still plans to put the Naval Strike Missile on the remaining Freedom-class hulls, Rear Adm. Fred Pyle, the director of surface warfare on the chief of naval operations’ staff (OPNAV N96), told reporters.” (1)
A US Marine Corps Logistics Vehicle System Replacement truck carrying a standard shipping container with a Navy logistics vessel in the background. The Navy is now working on a project to develop a containerized electronic warfare and electronic intelligence system that will work on various naval, air, and ground platforms. USMC / Lance Cpl. Shawn Valosin
The US Coast Guard has had a long history of participation in almost every armed conflict the US Navy has engaged in. But there has always been a tension between peacetime economy and effectiveness and readiness for war.
Some military systems are essential for our peacetime missions, like minimal deck guns or muti-mode radars, we would probably have them, even if we had no wartime missions.
Some military equipment we would be unlikely to have, if we had no military missions, can enhance performance of peacetime missions, like data links and electronic warfare systems. These systems are welcome.
Then there are systems that would enhance our wartime effectiveness that have little or no utility in peacetime. If they require significant training and maintenance time, they can adversely effective peacetime economy and effectiveness. There is an argument to be made that these still offer good return on investment compared with making a similar investment in DOD assets, but diverting DHS assets to support DOD missions can be a hard sell.
Ideally, we would want Coast Guard assets to do their peacetime missions without having to think about wartime missions until mobilization, but when needed, DOD would quickly and easily add capabilities and trained operating personnel.
That is not always possible, but in some cases we might be able to come close to that.
The Danes showed how to make modular naval weapon and sensor systems with their SanFlex system. Now we regularly see announcement of some new modular system. Here, here, here, here, here, here, here, here, and here.
TRAPS containerized active/passive towed array from GeoSpectrum Technologies.
Towed sonars can be containerized, here, here, and here.
What I think we need, after determining the most appropriate mission set for Coast Guard units is a determination of what:
must be permanently installed and operated by Coast Guard personnel at all times,
what can be quickly installed and operated in the event of a crisis, and
what can be added in the form of modular equipment maintained by the Navy and to be operated by Navy Reserve personnel upon mobilization.
A primary example of the latter would be an ASW helicopter. Unmanned systems also look like likely candidates for systems that could be quickly added to Coast Guard vessels.
Unmanned mine hunting and destruction equipment might be based on Coast Guard buoy tenders to allow them to look for mines in US waters, including those around Alaska, Hawaii, Guam and Saipan. In fact the Navy is making some extra LCS Mine CounterMeasures (MCM) for ships of opportunity.
If the Navy wanted Coast Guard cutters to augment Navy ASW forces, a likely mission if we have a war with China, they could become useful units by the addition of a modular version of the Navy’s towed array sonar systems and assignment of experienced ASW personnel and an MH-60R aviation detachment. We would need to have identified where we would store torpedoes, sonobuoys, and other support equipment, but those spaces could have other uses in peacetime.
USNS Hershel “Woody” Williams launches a Knightfish unmanned underwater vehicle (UUV) while at anchor in the Chesapeake Bay, Sept. 14, 2019. Photo: US Navy
“Capt. Mike Egan, branch head for mine warfare in the Office of the Chief of Naval Operations, speaking May 24 in Monterey, California, at the 2022 International Mine Warfare Technology Symposium of the Mine Warfare Association, said the MCM mission package is on track to achieve initial operational capability in the fall of 2022 and the Navy plans to procure a total of 24 packages.
“The Navy plans to equip 15 Independence-class littoral combat ships with the MCM mission package, which will leave an additional nine mission packages for use elsewhere.”
USN mine countermeasures ships are being decommissioned. Soon these mission packages will be the only US naval mine clearance assets. If a US port is mined, how will the mines be cleared?
Currently all Independence class LCS are based in San Diego. With the decision to shed all but six of the Freedom class LCS, none of which will be MCM capable, it is likely at least some Independence class will be based on the East Coast, presumably at Jacksonville. Aside from these 15 LCS mounted systems, it also appears the Navy will mount one on each of the five Lewis-B. Puller-class “Expeditionary Sea Bases” (ESB). That still leaves four MCM mission packages unclaimed.
LCSs based in San Diego and Jacksonville are still a long way from many US ports. In addition to transit time, the LCSs may be deployed or may not be available on short notice. The ESBs are all expected to be forward deployed, with one probably being assigned to each Geographic Combatant Commanders with the exception of Northern Command, e.g. Africa Command, Central Command, European Command, Indo-Pacific Command, and Southern Command, so they are unlikely to be available.
These four packages could provide mine clearance for US ports. One East Coast (perhaps Norfolk area), one West Coast (Seattle?), one Hawaii (Pearl?), and one in Alaska (Anchorage?) might be a logical distribution.
We know the disasterous effect of even short term port closures. Time is critical. The mission packages should be able to be deployed by air to the port(s) of interest. Some elements of the packages could certainly operate from shore. In many cases Coast Guard bases and air stations would be logical locations for temporary relocation of Navy assets. It is not unlikely Coast Guard fixed wing aircraft might be tasked with providing the air lift.
Some elements of the mission package, like the Unmanned Underwater Vehicles are still likely to require operation from floating units. Buoy Tenders would likely be able to fill this role. It might be worthwhile exercising this option, perhaps at RIMPAC.
Like many of you, I was unable to attend the Surface Navy Association Conference, but I did find a number of videos which may provide some of the information that would have been available there. The Coast Guard Commandant had been scheduled to speak but cancelled, apparently in response to the partial government shutdown.
I have provided three videos, each about ten minutes, that may be of general interest, and links to four others, typically 20-25 minutes. The descriptions are from their respective YouTube pages.
The second and third videos have specific Coast Guard content, which I have identified by bold typeface with the beginning time in parenthesis. Some of the other equipment may have Coast Guard applications in the future.
Day 1 video coverage at SNA 2019, the Surface Navy Association’s national symposium. In this video we cover:
– Austal latest frigate design for FFG(X)
– Raytheon DART Variable Depth Sonar (VDS)
– Raytheon / Kongsberg Naval Strike Missile (NSM)
– Lockheed Martin Long Range Anti Ship Missile (LRASM)
Day 2 video coverage at SNA 2019, the Surface Navy Association’s national symposium.
In this video we cover:
– Fincantieri Marine Group FREMM frigate design for FFG(X)
– General Dynamics NASSCO John Lewis-class T-AO (New Oiler)
– Raytheon SM-2 restart
– Raytheon SM-3 – Leonardo DRS Hybrid Electric Drive for U.S. Coast Guard’s Offshore Patrol Cutter (OPC) (time 11:10)
Day 3 video coverage at SNA 2019, the Surface Navy Association’s national symposium. In this video we cover:
– Atlas North America’s solutions for mine counter measures, harbor security and unmanned surface vessels
– Lockheed Martin Canadian Surface Combatant (Type 26 Frigate, Canada’s Combat Ship Team)
– Insitu ScanEagle and Integrator UAS (time 4:30)
– Raytheon SPY-6 and EASR radar programs
Vice Adm. Tom Moore, USN, the commander of the Naval Sea Systems Command, discusses US Navy efforts to increase public and private ship repair capabilities, lessons learned from repairing USS John S. McCain and Fitzgerald, the new Ford-class aircraft carrier, getting the Littoral Combat Ship on regular deployments and more with Defense & Aerospace Report Editor Vago Muradian at the Surface Navy Association annual conference and tradeshow in Northern Virginia.
George Awiszus, military marketing director of GE Marine, discusses the outlook for the company’s LM2500 engine that drives warships in more than 30 nations and the future of shipboard power with Defense & Aerospace Report Editor Vago Muradian at the Surface Navy Association’s annual conference and tradeshow in Northern Virginia.
Adm. Bill Moran, USN, the vice chief of naval operations, discusses dialogue with China, improving the surface force in the wake of 2017’s deadly accidents, refining Navy culture, increasing ship repair capabilities, harnessing data, improving information sharing across the force and the new Design for Seapower 2.0 with Defense & Aerospace Report Editor Vago Muradian at the Surface Navy Association’s annual conference and tradeshow in Northern Virginia.
Maj. Gen. David “Stretch” Coffman, USMC, the US Navy’s director of expeditionary warfare (N95), discusses new expeditionary warfighting concepts, the recent deployment of Littoral Combat Group 1 — composed of USS Wayne E Meyer (DDG-108) and USS Somerset (LPD-25) — to South America, new formations to replace the current Amphibious Ready Group and Marine Expeditionary Unit, unmanned ships, the performance of the F-35B Lightning II and more with Defense & Aerospace Report Editor Vago Muradian.
Earlier I suggested that LCS Modules, manned my Navy Reservists, might provide a mechanism that could cut mobilization time for Cutters from months to weeks. I also noted,
There are very few Navy mine counter measures assets in the US and those we have are not spread out geographically. If there were to be a peacetime mining incident in US waters, it might be possible to airlift an MCM module to the nearest cutter to allow the problem to be dealt with more quickly.
The US Naval Institute News Service has provided access to the “Littoral Combat Ship Mission Package Annual Report,“ and there is a note included that addresses this possibility. Nine Mine Countermeasures Mission Packages (MCM MP) are to be provided “for use on other Vessels of Opportunity (V OOs) to meet the warfighting capability requirements and account for MCM maintenance cycles.”
If there is a mining incident at a US port, the air and, in some cases, the unmanned surface vessel portion of the package could be operated from shore. Those portions that might need to operate from a ship could possibly be operated from buoy tenders or other cutters, not just the large patrol cutters.
We probably ought to be exercising this once the MCM MPs become available.
The Coast Guard has a rich military history, but we should recognize that, while we may be an “armed service,” we are not prepared for war.
We took the opportunity presented by the apparent end of the Cold War in the early ’90s to cut cost and overhead by removing recently installed anti-submarine warfare (ASW) and Harpoon launching equipment from the 378s and eliminating entire Sonar Tech (ST) rating.
Unfortunately, the holiday from worrying about a possible major conflict is over. China is challenging us, and Russia is resurgent. While it appears the Coast Guard has planned to provide some resources to address contingencies, it also appear we have no real direction as to what the Coast Guard will do if we have a major conflict. Certainly the new major cutters, the NSCs and OPCs, could be turned into credible escort vessels, but it would take months and their crews would need to be trained.
The development of modular systems for the Littoral Combat Ships (LCS) may provide a mechanism for rapidly upgrading our ships while Navy Reserves might provide the personnel and expertise to cut mobilization time from months to weeks.
The Navy currently has over 100,000 reservists, either Selected Reservists or Individual Ready Reservist, subject to recall. A number of them have expertise not resident in the Coast Guard, but useful upon mobilization. At one time these reservists might have gone to man Navy reserve frigates, but there are currently no navy combatants in reserve. As the number of LCSs increase the number of reservists with experience operating and maintaining the mission modules will increase. In addition all LCSs have two complete crews, so in wartime when they will presumably stop rotating crews, they will have an excess of active duty crews training in the mission module systems.
The primary mission modules planned for the LCSs are Anti-Submarine Warfare (ASW), Anti-Surface Warfare (SuW), and Mine Counter-Measures (MCM). It would not take much to make cutters capable of accepting all or parts of these mission modules, perhaps an OPC “B” class and during overhauls.
There is a very real possibility of inter-service synergy here.
A mission package of equipment, aircraft, sensors, and personnel could be loaded aboard for exercises, providing training for both the Navy and Coast Guard personnel.
The acoustic sensors from the ASW module might be deployed on a cutter bound for a drug interdiction mission in the Eastern Pacific, to help locate drug running semi-submersibles or if they are out there, submarines.
There are very few Navy mine counter measures assets in the US and those we have are not spread out geographically. If there were to be a peacetime mining incident in US waters, it might be possible to airlift an MCM module to the nearest cutter to allow the problem to be dealt with more quickly.
It now seems obvious that Unmanned Systems (air and possibly surface and subsurface) will play a part in the Coast Guard’s future, but the service has been, perhaps understandably hesitant to commit to any particular system.
Because of the variety of proprietary systems, integrating the control systems into the organization of the controlling unit, particularly ships and aircraft, and then integrating the resulting information into a common operating picture has been problematic.
Eaglespeak reports, it looks like DOD, through the Office of Naval Research, is moving in the direction of a platform agnostic software application that will permit common hardware to control different unmanned system.
This might permit Coast Guard units which commonly control small unmanned aicraft (sUAS) to be quickly adapted to
Control a much more capable UAS.
Hunt for mines using unmanned surface (USV) or subsurface (UUV) systems.
Control optionally manned surface craft to search for smugglers or enhance asset protection.
Control UUVs towing acoustic arrays, searching for submarines.
Direct a USV equipped with AIS, lights, and signals into position to serve as a temporary aid-to-navigation.
