“New Sonar For Navy Frigates Could Turn Any Ship into Submarine Hunter, Maker Says” –Defense One

Posted on January 19, 2023 by Chuck Hill

Combined Active Passive Towed Array Sonar, CAPTAS-4 in operation from a French Frigate. There are also smaller/lighter versions of the sonar.

Defense One reports on a presentation at Surface Navy Association,

“At the Surface Navy Association conference in Arlington, Virginia, this week, the company showed off a video of the technology being installed on a commercial ship within 48 hours, turning the vessel into an anti-submarine “asset,” Bock said.”

While mounting the sonar on merchant ships might be useful, wouldn’t it make sense to mount it first on Coast Guard National Security or Offshore Patrol Cutters that could also host an anti-submarine helicopter and are already equipped with Navy compatible secure communications?

On a cutter or a merchant ship there is the question of who would man it? Every year trained personnel, including sonar technicians and ASW helicopter flight crews, leave the active-duty Navy and become part of the Reserve. Upon mobilization, they can be recalled to active duty to man these systems.

“The Long Blue Line: LANTAREA’s PATFORSWA Managers—over 15 years of leadership!”

Posted on September 30, 2022 by Chuck Hill

MyCG has a new post that reports on the history of an element of Atlantic Area staff that has been manned by reservists, but it is more than that. It charts the history of Coast Guard efforts in support of Central Command over more than 16 years. It also reports that the Reservists are being releaved by an Active Duty/Civilian staff.

It is an interesting read.

Coast Guard Cutter + Navy Reserve + Mission Module = ASW

Posted on January 27, 2021 by Chuck Hill

The US is seriously short of Anti-Submarine Warfare escort vessels, but a little forethought and some cooperation between the Navy Reserve and the Coast Guard could seriously reduce the deficit, without a huge impact on either the Navy or the Coast Guard’s peacetime budget, operations, and manning.

It is a simple concept, a payload/platform solution. The Navy provides the payload. The Coast Guard provides the platform and drives “the truck.” It would allow the Coast Guard to have an important wartime role without significantly increasing its manning or training requirements. The costs to the Navy would be minimal and it would allow them to exploit their reserve pool of trained ASW personnel long before additional ships could be built.

In peacetime, the Coast Guard has been placing detachments on Navy ships. In wartime, Navy detachments could be placed on Coast Guard ships.

The essential elements are:

36 Coast Guard Cutters, 11 National Security Cutters and 25 Offshore Patrol Cutters built, building, or planned.
Navy Reserve Helicopter Maritime Strike (HSM) aircraft and crews
An ASW mission module for each cutter
Navy personnel (active or reserve, officer and enlisted) trained and experienced in operating the ASW mission module equipment and ASW operations

The Threat:

If we have a non-nuclear war with a near peer, e.g. China or Russia, it is almost certain we will need more Anti-Submarine Warfare escort vessels than we currently have. The Chinese have almost 80 submarines (60 conventional and about 19 nuclear) and they are doubling their capacity for building nuclear submarines. Russia has about 63 submarines, mostly nuclear.

US Navy ASW escorts, we are short:

The Navy’s force level goal is 156 surface combatants, out of the projected fleet of 355. These would include 104 large surface combatants (LSC, cruisers and destroyers) and 52 small surface combatants (SSC, LCS and frigates), but so far, there is no clear path to that goal. The Navy’s fleet will vary over time, but for the foreseeable future it will include less than 120 surface combatants. These include fewer than 90 cruisers and destroyers. A total of 35 LCS are built or funded, but it appears four of those may be decommissioned. Only ten LCS will be equipped as ASW escorts. The FFG(X), now FFG-62 program, is expected to produce 20 FFGs, but that program, is unlikely to produce its first ten ships before 2029.

The “Battle Force 2045” plan, which was never approved by DOD, projects a need for 60 to 70 Small Surface Combatants.

In any case we are going to short of escorts. A little over two years ago, the Military Sealift Command was told that ‘You’re on your own’: US sealift can’t count on Navy escorts in the next big war.

That is really not a good plan. We already have a minimal number of logistics support vessels and only a small pool of American mariners to sail them. Maritime Patrol Aircraft might be able to provide some degree of protection for transiting logistics vessels but one thing they cannot do, is rescue mariners from ships that are inevitably sunk. Coast Guard ships might be able to rescue mariners, but without ASW equipment, they themselves would be vulnerable.

The Mission:

I would not expect the cutters to be on the forward edge of battle, but by providing escort service from the Continental US to forward logistics bases, they would free more capable assets for areas where the threat level, particularly the air threat, is higher.

The Cutters:

The Coast Guard has or is building two classes of cutters that might be useful as ASW escorts, the Bertholf class National Security Cutters (NSC) and the Argus class Offshore Patrol Cutters (OPC).

USCGC Stone, the ninth National Security Cutter. Dual helicopter hangars clearly visible. (Huntington Ingalls photo)

Nine NSCs have already been completed. Two more are building or on order. Though they lack any current ASW capabilities, the Bertholf class National Security Cutters are in many ways already equipped to serve as frigates. A modified version of the design was apparently a contender for the FFG(X) program. They are a bit faster than the new FFGs and have a longer range and greater endurance. They have a flight deck and hangars capable of handling two MH-60s or one MH-60 and UAS. Like the new frigate and the LCSs, they have a 57mm Mk110 gun, but with a better fire control system than found on the LCSs, that includes a SPQ-9B Fire Control Radar. They also have a Phalanx CIWS and a sensitive compartmented intelligence facility (SCIF). They were designed with provision to accept twelve Mk56 VLS and Evolved Sea Sparrow Missiles. Their equipment includes:

EADS 3D TRS-16 AN/SPS-75 Air Search Radar
SPQ-9B Fire Control Radar
AN/SPS-79 Surface Search Radar
AN/SLQ-32B(V)2
2 × SRBOC/ 2 × NULKA countermeasures chaff/rapid decoy launchers
AN/UPX-29A IFF
AN/URN-25 TACAN
MK 46 Mod 1 Optical Sighting System (WMSL 750 – 753)
MK 20 Mod 0 Electro-Optical Sighting System (WMSL 754 – 760)
Furuno X and S-band radars
Sea Commander Aegis derived combat system
Link-11 and Link-16 tactical data links

The Offshore Patrol Cutters are only slightly less capable than the National Security Cutters. They are about the same size at 4,500 tons full load. Speed is lower at 22+ knots sustained. They also have a 60 day endurance and an over 10,000 mile range. They are designed to support and hangar both a helicopter and a UAS, but while they clearly could hangar a MH-60R, it is not clear if it could also support an MQ-8. It is currently unclear if they will have a SCIF as built, but they have space for one. Their equipment includes:

Saab Sea Giraffe AN/SPS-77 AMB multi-mode naval radar
AN/UPX-46 IFF
AN/URN-32 TACAN
MK 20 Mod 1 EOSS
Link 22 Tactical Data Link
AN/SLQ-32C(V)6 Electronic Warfare System
2 x MK 53 Mod 10 NULKA Decoy Launching Systems

Navy Reserve Helicopter Maritime Strike (HSM) squadron(s):

HSM squadrons fly both the MH-60R and MQ-8 Fire Scout UAS. Wikipedia reports there are currently 18 HSM squadrons. They are now the only provider of shipboard airborne ASW capability. Only one of those is a Reserve squadron. Reportedly the Navy currently has 34 excess MH-60R which could equip virtually all the large cutter currently planned.

The ASW Mission Module:

The Navy apparently intends to equip ten LCS with ASW mission modules. But the new FFG-62 class will share the same ASW equipment including the TB-37U MFTA (Multi-Function Towed Array) which takes the form of a three inch cable towed behind the ship. The LCS ASW module also includes a variable depth sonar, the AN/SQS-62. This may or may not be required for the cutters’ open ocean escort mission. Even 36 complete ASW modules at the current cost of 19.8M would cost less than a single new FFG.

AN/SQS-62 Variable Depth Sonar intended for Littoral Combat ships. Photo Raytheon.

Manning the ASW Modules:

There are at least two possible sources of crews to man the ASW modules:

Active duty personnel assigned to rotational crews of LCS and FFGs
Navy Reservists

All LCS are now expected to be manned by rotating Blue and Gold crews. A similar scheme is being considered for the FFGs. Upon mobilization it is likely crew rotations will stop. That may mean experienced ASW officers and crew will be available to serve on similarly equipped ASW capable cutters.

As of Sept 30, 2019, the Navy’s Ready Reserve Force included over 100,000 members, 59,658 Selected Reservists (SELRES) and 44,020 Individual Ready Reservists (IRR). Currently I doubt there are organized reserve units prepared to operate ASW mission modules, but that might be a future option that would allow them to operate with cutters during training and exercises, while maintaining their training using simulators. There will certainly be recently separated IRR members, trained in the operation of the relevant systems who could be recalled to active duty.

Conclusion:

This is a simple low cost way to add about 30% more ASW capable surface combatants to the fleet, putting it much closer to its projected requirements. They may not be ideal ASW escorts, but they may be good enough to make a difference.

“Our Integrated Naval Expeditionary Combat Force” –Navy.Mil

Posted on November 28, 2020 by Chuck Hill

A discussion of the close coordination between Navy, Marine, and Coast Guard elements within Navy Expeditionary Combat Command (NECC).

“Currently the Coast Guard provides approximately 50 reservists to NECC’s Maritime Expeditionary Security Groups 1 and 2, and Maritime Security Squadrons (MSRON). These Coast Guardsmen deployed with the MSRONs to Djibouti as integrated members of the staff since 2013. The integration in the MESF has been so seamless that the commander of the next MSRON unit deployed to Djibouti will be a Coast Guard officer.”

FY2019 Budget

Posted on February 18, 2019 by Chuck Hill

US Capital West Side, by Martin Falbisoner

With a bit of help from a friend, the actual FY2019 budget documents were located: “The Joint Explanation” and “The Conference Report.”

I found the Joint Explanation easiest to wade through. The Budget breakdown is found on pages 65 to 69 of the 612 page pdf.

Note in some cases I have rounded to the nearest $0.1M

Our total Coast Guard FY2019 budget is $12,015,921,000. This is $91,803,000 less than last year, but $577,720,000 more than the budget request.

The Operations and Support allocation is $7,808.2M. That is $434.9M more than last year (a 5.6% increase), and $215.1M more than requested.

I have provided information on the PC&I budget below including a complete list of line items that I was unable to provide before.

PROCUREMENT, CONSTRUCTION, AND IMPROVEMENTS (PC&I) $2,248.26M

Vessels and Boats

Survey and design: 5.5M
In service vessel sustainment: 63.25M
National Security Cutter: 72.6M (Follow up on ships already funded)
Offshore Patrol Cutter: 400M (Second of class + LLTM for third)
Fast Response Cutter: 340M (Six Webber class including two for PATFORSWA)
Cutter boats 5M
Polar Security Cutter: 675M (First of class + LLTM for second)
Waterways Commerce Cutter: 5M
Polar sustainment: 15M (Polar Star Service Life Extension)

—-Vessels Subtotal: $1,581.35M

Aircraft

HC-144 Conversion/Sustainment: 17M
HC-27J Conversion/Sustainment: 80M
HC-1330J Conversion/Sustainment: 105M
HH-65 Conversion/Sustainment: 28M
MH-60 Conversion/Sustainment: 120M
Small Unmanned Aircraft: 6M

—Aircraft Subtotal: $356M

Other Acquisition Programs:

Other Equipment and System: 3.5M
Program Oversight and Managemen: 20M
C4ISR 23.3M
CG-Logistics Information Management System (CG-LIMS): 9.2M

—Other Acquisitions Programs Subtotal: $56M

Shore Facilities and Aids to Navigation:

Major Construction; Housing; ATON; and Survey and Design: 74.51M
Major Acquisition Systems Infrastructure: 175.4M
Minor Shore 5M

—Shore Facilities and Aids to Navigation Subtotal: $254.91M

The PC&I total, $2,248.26M, was $446.48M less than FY2018, but it was $361.51M above the budget request.

—

R&D was cut by almost a third. This is probably a place to spend more not less.

Reserve Training disappeared as a separate line item, so I can’t tell what happened there.

Also included in the new budget is $5M for the National Coast Guard Museum

Incidentally, the total amount appropriated for the polar security program includes $359.6M (FY2018 and prior) + $675M (FY2019), or $1,034.6M, of which $20M is for Long Lead Time Material for the second ship, and the remainder is for the first ship and other program-related expenses.

With Operations and Support up more than 5% over 2018 and Procurement Construction &Improvement (PC&I) over $2B for the second year in a row, this is the kind of budget we can live with. It just needs to keep happening.

“Restructure the Coast Guard Reserves into Support Roles”–USNI

Posted on April 25, 2018 by Chuck Hill

The US Naval Institute Blog has a post recommending a restructuring of the Coast Guard Reserve, written by LCdr. Daniel L. Tavenier, USCG. His opening paragraph,

“The time has come to examine and consider restructuring the role of Coast Guard Reserves within the service. Currently, there is not enough time for reservists to adequately serve operational roles unless they were active duty for at least two years following accession. Reservists have brought much to the table as far as their civilian skill sets and experience go, but we cannot pretend they are able to achieve proficiency in certifications to the level of an active duty member. There has been a role for reservists to operate, but history has proven those instances are few and far between. As budgets shrink, the entire reserve program needs to be significantly modernized. This includes expanding the maritime security and safety teams (MSSTs) role to cover overseas missions and decommissioning port security units (PSU) that are staffed with 130 reserves and only six active duty members. PSU staffing models are not set up to meet the high-level, tactical certifications required for outside continental U.S. (OCONUS) operations. MSSTs have undoubtedly filled overseas duties at much less expenditure.”

Along the way he also recommends that we “Ditch the MAW” (Mounted Automatic Weapon), i.e., remove the M-240 machinegun from the small boats that do Ports, Waterways, and Coastal Security (PWCS).

This is way outside my wheelhouse, so I am going to leave evaluation and comments to the readers. If you have strong feelings about this, you might want to comment on the original USNI blog post. Duplicate comments are of course also welcomed here.

Building a 21st Century Infrastructure for America: Coast Guard Sea, Land, and Air Capabilities–House Subcommittee Hearing

Posted on June 23, 2017 by Chuck Hill

The hearing recorded above was held 7 June. The original video was found here. That page also provides the chairman’s opening statement and links to the witnesses’ written statements that are also provided immediately below. The video does not actually start until time 4:30.

Below, you will find my outline of the highlights.

Witness List:

Vice Admiral Charles W. Ray, Deputy Commandant for Operations, United States Coast Guard | Written Testimony
Vice Admiral Sandra L. Stosz, Deputy Commandant for Mission Support, United States Coast Guard | Written Testimony Ms. Marie A. Mak, Director, Acquisition Sourcing & Management Team, Government Accountability Office | Written Testimony
Mr. John Acton, Chairman, Coast Guard Affairs Committee, Navy League of the United States | Written Testimony

The GAO’s written testimony is particularly comprehensive. They report that new assets (NSCs and FRCs) are not meeting planned availability. There have been an unexpected number of engine replacements. In the case of the National Security cutters it appears to me the down time was predictable, a normal part of introducing new ships and availability should return to planned levels as more ships join the fleet. The known defect, that when operating in waters 74 degrees or warmer, the NSCs cannot maintain maximum speed has apparently not been corrected. Max speed must be reduced two to four knots to allow adequate cooling.

Planning Documents: The Congressional Representatives repeatedly complained that they were not getting an unsensored statement of the Coast Guard’s needs. It appears the Coast Guard is not being allowed provide this information. Rather it appears the GAO is telling the Coast Guard how much they will be getting and told to submit a budget that fits the predetermined amounts. Reportedly the Unfunded priorities list will be provided by the end of June. They also asked for the 5 year and 20 year plan (1h04:30). Coast Guard representatives were repeatedly told the Coast Guard does not say what they really need, that information provided by the Coast Guard is inadequate for the sub-committee to make decisions (1h48m).

It appears that the GAO continues to ask the Coast Guard to plan procurements based on historically low AC&I appropriations that were adequate for a time because of the sporadic character of Coast Guard ship building. They acknowledge that the current budget is not realistic. (43:45)

The Coast Guard is now consistent in requesting $2B in the AC&I annually and a 5% annual increase in its operating budget and that we need 5,000 additional active duty billets and 1,100 addtional reservists. There was a statement from one of the Representatives to the effect, We need you to fight for yourselves (1h50:30). The representatives were informed that the 5 year, 20 year plans and unfunded will be delivered together (1:56)

My opinion: we need a regularly revised Fleet Mix Study. That in turn should feed directly into a 30 year ship and aircraft procurement plan.

Webber Class WPCs: The Coast Guard is reportedly pushing WPCs operations down as far as the coast of South America. (50:00) This confirms my earlier speculation that these ships would be operated in what had been WMEC roles. Six cutters for CENTCOM The representative confirmed that they had approved procurement of six Webber class requested by CENTCOM. Apparently their approval was in the form of the Coast Guard reauthorization bill which has still not been made law. Adm. Ray stated that these would be in addition to the 58 currently planned (9:30) and it is not clear how or when they would be funded. Adm Stosz indicated it was not certain six Webber class would be the Coast Guard’s choice in how to fill this requirement and the question required more study. (1h11)(1h41m).

Shore Facilities: Reportedly there is a $1.6B shore construction backlog. $700M shore facilities maintenance backlog. Some infrastructure improvements that directly support new operational platforms.are being accomplished under the platform programs (55:00) The representatives asked, why we have asked for only $10M if the total shore facilities backlog is $2.3B?(1h35)

Icebreakers: The possibility of leasing the commercial icebreaker Aiviq is still being considered. (1h27) The owners have offered a plan for Ice trials and the Coast Guard has said it would be interested in observing. (1h29:50)

Great Lakes Icebreaker: Rep. Lewis brought up icebreaker for Great Lakes.Adm Ray says for now we will address with the existing fleet. (1h00:30) Priority is still Polar Ice Breakers.

eLoran: There seems to be considerable interest in eLoran to deal with GPS vulnerabilities. (1:22) The Navy League representative supported the need. The Re-Authorization Bill directs Secretary of Transportation to initiate E-Loran testing. There was a clear anticipation that the Coast Guard would support implementation.

Coast Guard Health Care: Looks like the Coast Guard heath care records system which reverted to paper now may be able to piggy back on the VA’s conversion to the DOD system. (1h25)/(1h32:30) There is currently a major gap in funding for medical care of CG retirees

A Better Armed Coast Guard: Not that the Representatives were specific, but there was a statement, “We want to weaponize you.” (5:55) I think I heard essentially a second time as well. I’m not sure what that means.

Rising Sea Levels: There was concern expressed regarding rising sea level and how they might impact shore facilities (1h12:20)

WMEC Service Life Extension: The Coast Guard was given money several years ago to plan a service life extension program for 270. The Congress has not seen or heard any result and they questioned, why delay? (1:09) See fig. 4 on page 17 of the GAO’s written testimony

Operating Expenses: Replacement ships are costing more.(26:25)(50:55). This is becoming problematic without an increase in operating budget.

Changing the way we buy ships: Included in the Reauthorization Bill are changes in the way the Coast Guard can fund its shipbuilding, putting us on par with the Navy (5:50)

Cyber: Budget includes 70 additional billets. (19:45) What are we doing for the ports? (1h13:45)

Inland Tender Fleet: Budget includes $!M to investigate alternatives. (52:30) (1h19)

It is remarkable that there seemed to be no sentiment that the Coast Guard budget should be cut, while there was considerable evidence the Representatives believe the Coast Guard is underfunded.

Brookings Institute–A conversation with Commandant of the U.S. Coast Guard Admiral Paul F. Zukunft

Posted on December 12, 2016 by Chuck Hill

Another video, this one almost an hour.

Commandant’s Strategic Intent, Mid-Term Report

Posted on July 1, 2016 by Chuck Hill

Procurement of 14 C-27J aircraft was one of the achievements sited. C-27Js replace C-130s at CGAS Sacramento.

The Commandant has issued a mid-term update on his earlier published “Strategic Intent, 2015-2019” (pdf). The new document is available in pdf format. You can find it here: “United States Coast Guard Commandant’s Strategic Intent, 2015-2019, Mid-Term Report.”

It is relatively short and readable at 21 pages. The recurring themes of the Commandant’s administration are all there, starting with TOC (transnational organized crime) and its deleterious effect on Western Hemisphere governance and prosperity. It does read a little like an Officer Evaluation Report input.

There is nothing particularly surprising here, but even for me, the enumeration of the scope the Coast Guard’s authorities, responsibilities, and international contacts is still mind boggling.

I am not going to try to summarize the report, but there were a few things that struck me.

The Commandant mentions service life extension programs for the seagoing buoy tenders (already begun), the 47 foot MLBs, and the 87 foot WPBs (in the future), but there is no mention of what we will do about the inland tender fleet. There will also be a life extension program for helicopters before they are finally replaced.

“Extend the service life of our rotary wing assets and align with DOD’s Future Vertical Lift initiative.”

There is mention of a program I was not aware of, the “Defense Threat Reduction Agency National Coast Watch System project.” The Defense Threat Reduction Agency attempts to track and reduce the WMD threat. It is not really clear what our role is here. We know about the container inspection programs in foreign ports. Is that it, or is there more to this? (that can be discussed at an unclassified level.)

“A Cooperative Strategy for 21st Century Seapower: Forward, Engaged, Ready” Kickoff, 13 March

Posted on February 25, 2015 by Chuck Hill

There is an upcoming event some of you might be interested in. It is the introduction of the new Navy/USCG/USMC strategy, “A Cooperative Strategy for 21st Century Seapower: Forward, Engaged, Ready”, slated for roll-out on March 13. Speakers include the Commandant, the Chief of Naval Operations, and the Commandant of the Marine Corps.

It will likely fill up quickly, so sign up soon if you want to go.

When: 3/13/2015 11:30 AM – 12:30 PM
Where: 1616 Rhode Island Avenue, N.W. Washington, DC 20036
Registration: http://my.csis.org/csis/CSIS1700/CSISEventRegistration.aspx?eventcode=2015_065
Cost: Free

Anyone want to be my on-scene reporter?
